Shalom!
It is time for the final episode in this three-part series
about learning to utilize parallel resources
in C++ programming.
In the first episode we explored how to extract the best performance
from a single CPU core.
In the second episode, we learned to utilize
all cores within the CPU.
But what would be even more efficient,
than utilizing a processor to the maximum?
Well, of course, utilizing more than one processor!
So, how exactly could we go about doing that?
How about using multiple identical processors?
This is no different than using multiple CPU cores,
and we already covered that in episode two.
So, scratch that off the list.
How about using multiple computers?
This is called cluster computation, or clustering.
Clustering is usually, but not always,
done on operating system level with tools such as MPICH.
The same program is started on multiple computers,
with data collected in one place.
It usually does not require any changes
into the program's source code,
and that kind of thing is not what I had in my mind.
That leaves option three: Using multiple different
processors.
Within modern PC hardware, there is often found
a very powerful coprocessor.
This coprocessor is the graphics processing unit,
or GPU for short.
The GPU is capable of general purpose computation,
much like the CPU,
but with advantages and disadvantages:
Unlike the CPU, which can run maybe four or sixteen threads,
the GPUs have hundreds or even thousands.
According to the Steam Hardware & Software survey of May 2017,
the most popular gaming graphics gard –
is currently the NVidia GTX 750 Ti.
It has 640 CUDA cores.
The GTX 1080 Ti, released just couple of months ago,
has 3584 CUDA cores.
And guess what?
The GNU Compiler Collection (GCC) supports it.
Computing on a device is called "offloading".
Right now, GCC supports offloading to three different platforms:
NVidia PTX-enabled graphics cards;
Heterogenous System Architecture, or HSA for short,
which is only still used for –
offloading code to AMD graphics cards;
and Intel Many Integrated Core architecture, or MIC for short,
which is mainly used for running code on –
Intel Xeon Phi coprocessors, which are based on the x86 architecture,
but are capable of running 256 concurrent threads or more.
Sadly I don't have one.
They are quite expensive.
Offloading works like this:
You write a single program.
Within that program,
some parts will be compiled to be run on the host computer,
and some parts will be compiled to be run on the device.
Some parts may be compiled for both.
The same goes for constant data, and also for variables.
The device and the host computer might not share RAM,
which means that all arrays and other data –
must be passed back and forth between these units.
Offloading in GCC is done with –
one of the following two standard extensions:
OpenMP and OpenACC.
These features are not usually enabled –
in your Linux distribution.
You can enable them by building GCC from source code.
Instructions can be found on the GCC website.
Let's study OpenMP first.
Our baseline program is the vanilla single-threaded –
non-SIMD Mandelbrot fractal renderer –
that I introduced in episode 1.
The plan is to have the heavy stuff —
the fractal calculation —
all happen on the external device.
So, Iterate is declared as target code.
Anything declared between these two pragmas –
will be compiled for the target device,
not for the host.
Then, some reorganization,
to put all the target device code in one place,
and the host device code in another place.
Separate those two parts.
The offloading itself happens with a single pragma,
just like was the case for parallelization in episode 2.
Finally we take the resulting iteration counts –
for each pixel using a STL library call,
and convert the iteration counts into colors locally,
which is a quick operation.
Let's review the components of the OpenMP pragma.
The word "target" means that the next statement –
will be run on the device rather than on the host.
The word "teams" means, that on the device,
a league of teams will be created.
This means that instead of a single team of threads,
there will be multiple groups,
or gangs or blocks or teams, whatever you want to call them,
and each of them contain multiple threads.
"Distribute parallel for" means –
that the following for-loop will be divided –
among those threads,
so that each iteration will be run exactly once –
in unspecified order,
but multiple iterations may run concurrently.
"Collapse(2)" tells OpenMP that –
the following two for-loops should be treated as one unit;
all combinations of the iterations of the two loops –
should be distributed across threads.
Without the collapse keyword,
only the outer for-loop would be distributed,
and the inner for-loop would be run consecutively –
by each thread.
The "map" keyword controls the relationship –
between host memory and device memory.
Specifically, we send these variables "to" the device,
and once the device has done calculating,
we receive the "results" array "from" the device.
When you run the program that uses OpenMP offloading,
you use the OMP_DEFAULT_DEVICE environment variable –
to choose which device to run on.
In my case, I want to run it on the NVidia GTX 970,
so I select OMP_DEFAULT_DEVICE=1.
And the results are!
Huh?
… Wha?
… I don't understand.
Why is it slow?
It is definitely running on the GTX 970,
according to nvidia-settings .
O-kay…!
Now it crashed.
L-let's move ahead;
maybe there will be an explanation later.
OpenACC!
OpenACC is a different standard by different people,
that does pretty much the same as OpenMP,
except its focus is totally on offloading,
where as OpenMP began –
from making native parallelism easy.
Translating OpenMP pragmas into OpenACC pragmas –
can be easy or it can be difficult.
At easiest, it is just a change of terminology.
What OpenMP calls a team, OpenACC calls a gang,
and so on.
OpenACC defines a very elaborate memory model –
involving allocations.
It would take me at least half an hour –
to describe how it all works,
but in this example –
I just copy data in and out.
Done.
Let's check out the performance.
It is… eh, well,
it's faster than the OpenMP offloading version,
but still much slower than the vanilla offloading version.
And it crashed too.
Apparently it hit a watchdog timeout.
It turns out –
that the NVidia driver kills the task –
if the function runs for more than seven seconds.
Now, it is quite surprising –
that the GPU-accelerated program is slower than a native program,
but there may be an explanation.
Graphics cards may have hundreds or thousands of threads,
but what they have is actually –
functionally closer to SIMD than to threads.
The GPU acceleration works best –
with programs where the exact same calculation –
is performed on a large set of data.
Unlike CPU SIMD,
GPU acceleration can cope with situations –
where the calculations diverge into different branches –
using if-elses,
but the performance will suffer greatly –
whenever that happens.
To give GPU acceleration the final benefit of doubt,
I went ahead and translated the program into CUDA.
This means that instead of GCC,
we will use NVidia's NVCC –
to compile the program.
CUDA is actually –
just a fancy name for plain old C++,
with some extensions.
You heard it: CUDA is C++.
If you can write C++, you can write CUDA.
Now, the extensions that make CUDA useful are:
Each variable declaration can be prefixed –
with an optional attribute: Constant, device, or shared.
These attributes deal with read/write access and lifetime.
Each function declaration can be prefixed –
with an optional attribute:
Device, host, device host, and global.
The entry-point between host-code and GPU code –
is called a kernel, and it is indicated –
by the __global__ keyword.
Kernels are invoked using a special syntax –
that resembles the C++ template parameters.
The two parameters within these special brackets –
are the number of blocks,
and the number of threads per block.
These parameters are actually three-dimensional entities,
but I usually treat them as scalars.
Within the kernel, the compiler defines –
a set of variables, that can be read:
blockDim, which is same as the block dimension –
that was passed in the special bracket parameters.
blockIdx is the currently being executed block index.
It runs from zero to the block dimension.
threadIdx is the currently being executed thread index.
It runs from zero to the thread limit –
that was passed in the special bracket parameters.
warpSize is –
architecture-dependent number of threads per warp.
The warp is equivalent to a SIMD unit size.
Imagine each of these Chinese letters is a single thread.
A single block can include a number of threads,
but all threads belonging to a single warp –
always execute exactly same code, for different data.
If your SIMD code contains branches,
the GPU will temporarily stop all the other threads –
in the same warp,
because threads belonging to one warp –
can only execute one sequence of code.
Essentially the performance would diminish –
by a factor equivalent to the warp size.
The good news is that unlike in CPU SIMD,
the GPU driver can actually migrate threads between warps –
to utilize them more efficiently,
but this is only a best-effort process –
and how exactly it works –
is neither disclosed nor set in stone.
CUDA also defines some vector datatypes.
These are vector datatypes in name only;
CUDA hardware contains no SIMD instructions,
because the hardware itself is a SIMD machine.
According to my tests,
there is no performance benefit to using these.
And, CUDA contains a huge library –
of functions both for the host and the device.
And by huge, I mean it is massive.
There are like 150000 lines of physical code –
in the header files alone.
That number is within the same ballpark –
as the amount of code in a recent Linux kernel,
and that was just header files.
You could spend a year –
just learning how to use all those libraries.
When converting the fractal renderer –
into a CUDA program,
the first order business is –
to convert the Iterate function into a kernel.
This is done by adding the __global__ attribute.
Now because this function will be called thousands of times –
with identical parameters,
with only the block and thread indexes –
differentiating the different calls,
we will need a couple of more data items –
to make the parameters useful.
Namely, the center coordinate in the fractal, the zoom scales,
and a pointer to where all the results will be stored.
Of course, to invoke the kernel, we will use the bracket syntax –
introduced at 9:46 in this video.
The number of blocks times the number of threads –
must be at least as big as the results array.
I set the number of threads arbitrarily as 128,
and the number of blocks is calculated from the need.
Now the GPU code cannot write directly –
into the host computer's memory,
so we need to allocate memory directly from the graphics card.
The cudaMalloc function allocates GPU memory.
This memory pointer will be passed to the kernel,
and the cudaMemcpy function, invoked here,
will copy the data from the GPU memory –
into the host memory,
once the GPU code has done executing.
Here we go!
Ah.
Finally, it's faster than anything else so far.
It dances a little with the OpenMP thread version,
but then shakes it off with a huge margin.
In the end, this is 17 times faster –
than the vanilla version,
and 2.5 times faster than the thread loop.
Can I make it faster?
Well first of all –
I think the transfer between GPU and host memory –
may be a bottleneck.
I should at least try to see what happens –
if I reduce the array of 32-bit floats –
into an array of 16-bit ints.
I should also try multiple streams.
CUDA operates using a stream of operations.
A stream is like a pipe –
from which the graphics card driver pulls tasks,
that it processes in a sequence.
Right now my stream looks like this.
Calculation, transfer, calculation, transfer.
Each period of calculation –
is followed by a period of memory transfer.
During the memory transfer,
the CUDA cores are actually idle,
waiting for work.
But it is actually possible –
to have more than one stream in CUDA.
If I start another task in the second stream –
when the first stream begins transferring data,
and vice versa,
the calculation tasks on GPU would be performed back to back,
with absolutely no idle time.
It would mean perfect 100% GPU utilization.
Let's try that.
So, two streams.
To support the two streams –
we need all kinds of book-keeping.
There is a counter for the next stream to be occupied,
the number of streams currently processing data,
and flags indicating the same.
They are created with the cudaStreamCreate function.
The memory buffers must also be duplicated.
The memory copying will now happen –
with cudaMemcpyAsync, meaning it will proceed asynchronously.
All of the remaining changes to the main program –
are just gymnastics around the asynchronous relationship –
between the calculations and the processing of the results.
The main loop now begins with interpreting the results;
that is,
converting the array of iteration counts into pixels,
rendering the pixels,
and updating the inaptly named boolean variable "NeedMoment" –
that controls whether –
periodicity checking will be enabled for the next frame.
Before we can assume the results are available,
the cudaStreamSynchronize function must be called.
It waits until all commands in the specified stream –
are completed.
The result is a very slight performance improvement.
And by very slight, I mean –
it's almost no improvement at all.
In the end it's like a single percent faster –
than the first CUDA version.
Totally negligible.
As expected, the margin to the CPU versions –
is greatest when the majority of the iterators –
run for a long time.
Any time that different iteration loops branch –
at significantly different moments,
such as in the very beginning, at the outermost zoom level,
the CUDA engine performance suffers –
for reasons that were explained at 10:57 in this video.
Finally, I made a version that combines best techniques –
from all three episodes.
First, there are two CUDA streams.
In addition, there are eight native C++ threads,
each of them calculating the image –
using SIMD acceleration.
In total, there are ten processing units,
each of them responsible for a single picture.
Because of this,
different frames take wildly different times to calculate.
The following chart actually is actually smoothed data –
where the elephant-size variations –
between the render times of different frames –
are somewhat evened out.
In the end it is about forty times faster –
than the vanilla version.
Now I know what some of you are thinking.
I know, because I thought the same.
Isn't there overhead –
in calculating multiple frames in parallel?
Would it not be better for cache efficiency –
to work on a single frame using multiple threads?
Cache efficiency notwithstanding,
it is actually faster –
to calculate multiple frames in parallel –
as you can see from this chart.
The reason is that –
when you process a single frame using threads, say,
by assigning each scanline to the next available thread,
there is a situation when the frame is almost complete,
where some threads are idle, but some are still working.
The next frame cannot be started before all threads are finished.
And this moment, where some threads are idle,
just does not exist –
when you process multiple frames in parallel.
Now you might think:
How about if we start assigning threads –
to the next frame when they become free,
while some threads are still calculating –
the previous frame,
instead of waiting until the previous frame is complete?
I thought that too.
In fact, the chart you see on the screen –
is the result of that thought process –
carried to its end.
The one I described earlier was even slower.
Oh.
This screen again.
Does this mean I should say some words, –
like "conclusion" or something?
Ah.
Yeah.
I know I pulled some lines straight –
and made some inaccurate generalizations here.
For instance, CUDA is not actually C++.
NVidia's NVCC is based on LLVM,
and can add the tiny CUDA extensions –
to many different languages, like Fortran for instance.
Essentially the same principle as with OpenMP,
but still different some way.
The purpose of this video series –
was to give you some ideas and inspiration,
to help you look –
where you didn't know to look before.
There are other people –
who make comprehensive references and tutorials.
In any case,
please do check the video description –
and the links therein for all the information –
that I could not pack into the video itself,
and check out the comments on the video as well.
I will also gladly reply to all polite comments,
although I do hope you do your research first –
in case it's a frequently asked question.
Thank you for all your support.
Thanks to people who translate captions to different languages!
Huge thanks to all 35000 and more –
people who have hit the subscribe button.
You are awesome!
I wish everyone was like you.
Thanks to people who give me awesome ideas –
for future videos and livestreams,
by asking fascinating questions in the comments.
I hope you all have a fantastic day.
See you again.
For more infomation >> Щенячий патруль новые серии Приключения АМ НЯМА Мультик для детей АМ НЯМ Игрушки Видео для детей - Duration: 8:20.
For more infomation >> 【風吹草動】PG-13 保羅·喬治正式宣布不會與溜馬續約【中文字幕】 - Duration: 0:43.
For more infomation >> Stitchers 3x03 Sneak Peek "Perfect" (SUB ITA) - Duration: 1:24.
For more infomation >> Misook Wang - Duration: 43:34.
For more infomation >> Haunting Memories - Duration: 42:34.
For more infomation >> Звезды бросили Диану Шурыгину на день рождения (19.06.2017) - Duration: 2:11.
For more infomation >> Community capacity and peer support - Duration: 2:42.
For more infomation >> Proactive coordination of care - Duration: 2:37.
For more infomation >> Personalised care and support planning - Duration: 3:18.
For more infomation >> Ford Ka 1.2 Comfort start/stop - Duration: 0:49.
For more infomation >> Choice and control - Duration: 2:11.
For more infomation >> Mercedes-Benz B-Klasse B 180 Urban Automaat - Duration: 0:42.
For more infomation >> Mercedes-Benz B-Klasse 160 BLUE EFFICIENCY BUSINESS CLASS Airco Navigatie Audio 95Pk! ZONDAG A.S. OP - Duration: 0:46.
For more infomation >> Cattywampus in Ann Arbor - Duration: 40:04.
For more infomation >> Рецепты из тыквы вкусные и простые - Duration: 2:54.
For more infomation >> Вкусно и просто домашние рецепты с фото - Duration: 3:07.
For more infomation >> Nissan QASHQAI 1.2 N-Connecta 115pk Automaat*Navi*Panoramadak* - Duration: 1:00.
For more infomation >> [M/V] Produce101 - Always (이 자리에) - Duration: 4:08.
For more infomation >> BMW 3 Serie 330I M SPORT Schuifdak Navigatie Alcantara Harman Kardon Xenon 17"LM 272Pk! ZONDAG A.S. - Duration: 0:59.
For more infomation >> BMW X3 3.0d High Executive M. Sportpakket Panoramadak Afn. Trekhaak 19"LM 218Pk! ZONDAG A.S. OPEN! - Duration: 1:01.
Không có nhận xét nào:
Đăng nhận xét
