Hi everyone, and welcome to the FLOEB channel
for a new review, with 1 product coming from belgium, the hydraulic handbrake from simtag, I show you immediately in detail
Let's go!
Here is the simtag handbrake in detail, the simtag handbrake is based on a real model
for fans of rally and drift
It mesures 37 cm long and 30 cm to 51 cm high.
with lever extension
it weighs
1855 g
the base of the handbrake is in metal, covered with a black paint, the lever has a thickness
of 8 mm
the knob has a diameter of 2.8 cm and a height of 9.8 cm
there are six rubber rings
the grip is very good! at the base level,
metal studs 2 mm thick
with the four holes on the bottom to fix the handbrake on the rig
the angle of the lever can be adjusted with the nut and the threaded rod
a spring has been added by simtag
to improve the feeling, a spring 3.7 cm in diameter
you can also change the position of the lever, in vertical or horizontal position
from 30 to 90 degrees
then we can change
the position of the lever, in the vertical position, like this one! or in a horizontal position!
for this you need the flat key of 13, at first,
I unscrew
maximum threaded rod
simply to remove it from the metal part, pull the rod out of the metal part
to change the position of the lever, it's here, you have to remove
the two clips, we have 1 on each side
small clips 1 mm thick,
we remove them,
Then, just remove the small metal part, the small axis
7 - 8 mm in diameter
after we release, in fact
The lever!
and we equip ourselves with an Allen key
To remove
The axis on the bottom of the lever, therefore, the Allen key on one side,
and the flat key of 13 of the other,
Many options on this handbrake, we can really adapt easily to its simrig
That's it, the lever is 8 mm thick! there is also
Two metal parts
which serve as spacer
and a long screw
BTR, black
then, for reassembly
you have to put the axis back down, at first
I put the screw with a spacer
Then I put the lever back
nothing complicated!
just take your time, here, reinstall properly
I put the metal washer back
With the nut
I'm tightening
And now, I'm replacing my little metal axis!
here
I put my two small clips, 1 on each side, in the grooves of the cylindrical axis
it's very fast, frankly it's very simple,
and I have my handbrake in a horizontal position !!
therefore, for the handbrake with the lever in horizontal position
I can
also
adjust
the angle of the lever
if I screw, the lever goes up and if I unscrew, it goes down
on the lever, we have a possible setting,
from 30 to 90 degrees, whether horizontal to vertical,
a large choice of settings
we have
a very good handbrake! with the spring
added by simtag, for the feeling, for a better feeling!
on the back, material, from the world of the automotive
with 1 wilwood master cylinder, 1 wilwood slave receiver, quality metal hoses!
DOT3 oil and a bosch pressure sensor! quality components for this handbrake !!
it is supplied with a black elastomer and 2 red elastomers
the black is soft and the red is hard, the handbrake was delivered with the black rubber
and the feeling is very good, we can adjust
the feeling with the nut on the back of the receiver, modifying the elastomers,
and tightening the nut more or less strongly
then, on the handbrake, on the wilwood receiver
we can also change the feeling in the lever,
with the flat key of 13, I take off
the nut on the back
there is a metal washer 2 mm thick
and discs
I think it's plastic, it's the same as on
the simtag pedals, if you saw the review !! 2 mm thick plastic discs
which serve to fill the empty space
it is installed originally 1 black rubber, black is a flexible rubber,
I have a very good feeling with the handbrake in vertical position,
without the extension, I specify!
we can, for example, put
1 red rubber for a harder feeling, or even
put two rubbers, if you want a really hard handbrake
after, as I tell you, I really had a very good feeling with black rubber
therefore, for the handbrake in vertical position and without the extension! I reinstalled as originally
now I replace the discs
on
The threaded shaft
And in fact, I can also
change the feeling in the lever
by tightening this nut more or less, the more I use it and the more I will have
a hard Feeling in the lever
after all is set to the millimeter, it's like the pedals, it's really good
Here! the more I tighten
the nut
the more I compress the rubber
which is why I have
a much harder feeling in the lever, I had really put it to a minimum,
I put back as originally and frankly, I really have a good feeling
in the lever
the handbrake comes with a bodnar cable, the same cable that is delivered for the simtag pedals
it records the data. a cosworth connector
anti moisture and anti dust, high quality connectors
I plug on the bosch sensor
That's it, it's clip and
The handbrake is delivered with a usb cable of a length of 1 m 40, we can easily connect to the pc
and there I just come
plug it in
The bodnar cable, simply
and I can connect my usb cable to the pc
the price for this handbrake is 590 euros + VAT + shipping costs
I install it on the rig and I give you my feeling in game
I am in the pit of lucas oil raceway, with the Ford fiesta, I test the hydraulic handbrake
from simtag and I make a small conclusion !! Let's go!!
we left for a few laps, test, the simtag hydraulic handbrake
Available on their website !!
I will put the link in the description of the video
The first turns, very good feeling with black rubber
Good feeling, after, if you add the extension, it may be necessary to put a red rubber
Yeah! very precise!! good grip
a knob with a small diameter, the rubber rings, it's perfect!
the handbrake is plug and play
but you can also adjust, for example, the dead zone, on the interface of Leo Bodnar
the same interface that I presented to you for the simtag pedals, if you want to see the review, the interface is very simple
personally, I settled directly in IRACING
it's perfect
we have a handbrake with quality components from the automotive industry
I finish the lap and I make a small conclusion but it's excellent
very precise, a good grip
That's it, the simtag handbrake test is over, the positive points I give
the components that equip this handbrake, we have components from the real world of the automotive
with a bosch pressure sensor, cosworth connectors
wilwood master cylinder and slave receiver
a very good feeling, it must be emphasized, in the game, it's really good, good work
and the negative point that I give to this handbrake, the price!
since it costs 600 euros for the handbrake, it's a big budget
here, I put you the link in the description of the video if you are interested by the simtag hydraulic handbrake
I thank them for the confidence they gave me to make this review! do not hesitate, to like my facebook page
subscribe to the youtube channel and I give you appointment for a next review !! BYE !!!
